Pulveriser Machine Details
Description
POLYMER SIZE REDUCTION PULVERISER MACHINE
Dev Plastotech make latest technology size reduction complete pulverizing machine especially designed to uniformly pulverize various grades of polymers like LLDPE, LDPE, RPVC, CPVC, HDPE etc. The complete system has been designed and comprise of the following parts and assembly.
Features
- Complete Robust & very sturdy structure for sound & vibration free operation.
- Electromagnetic vibrating feeder for uniform & controlled feeding of material.
- Main Grinding disc of special hardened material & gas Nitride for longer life.
- Effective water cooling system for main mill body Grinding Disc & Bearing housing.
- Temperature monitoring of Disc Mill & thereby ease of control on feed rate.
- Vibratory screen for effective separation of course & fine particles of pulverized materials.
- Air lock valve assembly with cyclone hopper for effective separation of air & pulverized material.
- High speed blower with motor for efficient suction of grinded material E to convey up to the cyclone system.
- Electrical panel with dust proof construction equipped with reputed make Electrical switch gears & with all necessary controls.
- All components & bought outs parts are of reputed & reliable make.
- Complete machine with superior grade paint with five stage process.
Specification
| Perticular | Unit | DEPV-150 | DEPV-300 | DEPV-600 |
|---|---|---|---|---|
| Main Mill Motor AC | Kw | 18.25 | 30.00 | 56.25 |
| Vibrating Screen dia | Kgs/hr | 120 - 150 | 250 - 300 | 500 - 600 |
| Working area Req : L x W X H | Mtr | 2.8 X 2.8 X 3.8 | 3 x 3 x 4 | 3.5 x 3.5 x 5 |
| Total load : | Kw | 22.00 | 39.15 | 67.50 |
